Rotex
Vertical single-stage centrifugal pump with discharge to the top and parallel with the pump shaft, pump base designed to act as suction strainer. Pump and motor are rigidly connected by a support column. Supplied ready to be plugged in, with 1.5-metre power cable and level switch.
-
Advantages
– Ready-to-connect, easy installation and commissioning
– Automatic operation by level control with displacement weight or float switch
– Easy to install thanks to low weight, compact design and ready-to-connect system
– Maintenance-free thanks to grease-packed deep groove ball bearings sealed for life and product-lubricated plain bearings -
Suitability
Vertical shaft submersible pump
-
Technical Features
- Max. flow rate
- 24 m3/h
- Max. head
- 14 m
- Maximum allowable fluid temperature
- 90 °C
-
Downloads
Click below to download
