Description
Need a freshwater supply pump? Our Jabsco Par-Max Series has got you covered. Pressure controlled diaphragm pumps provide boat owners with a freshwater system that’s as easy to use as the one in their homes.
With our lineup of Jabsco freshwater supply pumps, not only are we sure we’ll have a pump to meet your needs, we’re certain you’ll get years of satisfactory service out of it.
Our HD Par-Max Series of pumps, including the Par-Max HD3, Par-Max HD4, Par-Max HD5, and Par-Max HD6, include a wide diameter motor with a powder coated shell, cast aluminum endbells, and lower housing to improve pressure capability. Our standard models, including the Par-Max 1, Par-Max 2, and Par-Max 3, provide good performance in an economical footprint. With configurations available in 1-6 GPM (3.8-22.7 LPM), the Par-Max Series is perfect for vessels with 1-6 outlets.
Model Numbers
- 42630-3512-3C Par-Max 1
- 31295-3512-3A Par-Max 2
- 31295-3524-3A Par-Max 2
- 31395-2512-3A Par-Max 3
- 31395-2524-3A Par-Max 3
- 31395-4012-3A Par-Max 3
- 31395-4024-3A Par-Max 3
- Q301J-115S-3A Par-Max HD3
- Q301J-118S-3A Par-Max HD3
- Q402J-118S-3A Par-Max HD4
- Q402J-115S-3A Par-Max HD4
- Q402J-112S-3A Par-Max HD4
- Q401J-118S-3A Par-Max HD4
- Q401J-115S-3A Par-Max HD4
- Q401J-112S-3A Par-Max HD4
- P501J-115S-3A Par-Max HD5
- P501J-118S-3A Par-Max HD5
- P601J-215S-3A Par-Max HD6
- P601J-218S-3A Par-Max HD6
- P602J-215S-3A Par-Max HD6
- P602J-218S-3A Par-Max HD6
-
Advantages
Product Features
- Accommodating flows from 1 GPM (3.8 LPM) to 6 GPM (22.7 LPM)
- Co-molded diaphragm technology ensures long life and durability
- Heavy duty (HD) models feature motors and cast aluminum lower housings for longer life even at high pressures
- Efficient and quiet operation and no vibration thanks to dampening mounting feet
- Integrated, sealed pressure switch for on-demand operation
- Versatile installation thanks to its self-priming capability
- Running dry without damage
- Quick-connect ports make for easy installation and servicing
- Reduced cycling and smoother flow thanks to integrated bypass module
-
Suitability
Diaphragm Pumps
-
Technical Features
Specifications Par-Max 1 Par-Max 2 Par-Max 3 Par-Max HD3 Par-Max HD4 Par-Max HD5 Par-Max HD6 Open Flow 1 GPM (3.8 LPM) 2 GPM (7.6 LPM) 3 GPM (11 LPM) 3 GPM (11 LPM) 4 GPM (15 LPM) 5 GPM (19 LPM) 6 GPM (23 LPM) Voltage Options 12 VDC 12 VDC, 24 VDC 12 VDC, 24 VDC 12 VDC 12 VDC, 24 VDC 12 VDC 12 VDC, 24 VDC Pressure Switch Options 35 PSI 35 PSI 25 PSI, 40 PSI 40 PSI, 60 PSI 25 PSI (EU only) 40 PSI, 60 PSI 40 PSI, 60 PSI 40 PSI, 60 PSI Quick Connect Strainer Not included Inline 40 mesh Inline 40 mesh Inline 40 mesh Inline 40 mesh 90˚ 40 mesh 90˚ 40 mesh Quick Connect Straight Hosebarb Fittings 2 x 3/8″; 2 x 3/8″ to 1/2″ adapter 2 x 1/2″ 2 x 1/2″ 2 x 1/2″ 2 x 1/2″ 2 x 1/2″; 2 x 3/4″ 2 x 3/4″ -
