Wilo Yonos Maxo Range

Wilo Logo

The Wilo-Yonos MAXO is a glandless circulation pump with threaded connection or flange connection, EC motor with automatic power adjustment.

Description

High efficiency light commercial circulator pump with 4m max head, 220 mm port-to-port length and DN40 flanged connections The Wilo Yonos MAXO range are high efficiency glandless light commercial circulator pumps designed to enable quick and simple installation. The Yonos MAXO-D pumps are twin head units.
Applications
The Wilo-Yonos MAXO can be used for the following applications:
- All Hot Water Heating Systems
- Air Conditioning Applications
- Closed Cooling Circuits
- Industrial Circulation Systems
Features
- Maximum efficiency thanks to ECM technology
- LED display for showing delivery head setting
- Quick and convenient electrical connection with Wilo-Connector
- Collective fault signal on all types for assuring system availability
- Simple installation due to PN 6/PN 10 combination flanges (with DN 40 to DN 65)
- Can be used in cooling/air-conditioning systems without ambient temperature limits
- Pump housing with cataphoretic coating for preventing corrosion due to condensation formation
Materials
- Pump housing: grey cast iron with cataphoretic coating
- Shaft: Stainless steel
- Bearing: carbon, metal impregnated
- Impeller: Plastic
Specifications
- Permissible temperature range of -20°C to +110°C
- Mains connection 1~230 V, 50/60 Hz
- Protection class IP X4D
- Flange connection DN 32 to DN 80
- Max. operating pressure of standard version: 6/10 bar or 6 bar (special version: 10 bar)
Downloads

Why the Wilo Yonos Maxo Range…

EC Motor with Automatic Power Adjustment

Highly Efficient

Low Vibration & Noise

LED Display

Cataphoretic Coating to Prevent Corrosion

Suitable for Cooling/Air-Conditioning Systems
