Ksb – PROFIN VT3
Ball valve to ANSI/ASME with flanged ends, threaded ends (BSP) or long butt weld ends, three-piece body, full bore, solid ball, blowout-proof shaft, body made of stainless steel.
-
Description
Main Applications
– Building services
– Industrial plants
– Water
– Air-conditioning systems
– Condensate transport
– Cooling circuits
– Fire-fighting systems
– General irrigation systems
– Pressure boosting
– Process engineering
– Snow-making systems
– Swimming pools
– Washing plants
– Water supply systems -
Advantages
– Added safety by blowout-proof shaft
– Valve can be locked in open or closed position.
– Minimum pressure loss by hydraulically favourable flow passage -
Suitability
Ball valve
-
Technical Features
- Nominal pressure
- PN 40
- Max. nominal size
- DN 100
- Maximum allowable fluid temperature
- 150 °C
-
