Ksb – ECOLINE GTV 150-300
Gate valve to ANSI/ASME with flanged ends, cast steel A216 WCB, A351 CF8/CF8M/CN7M, Trims 2/8/10/13 for Class 150/300, with bolted bonnet, outside screw and yoke, non-rotating stem, flexible wedge, graphite gland packing, stainless steel / graphite gasket.
-
Description
Main Applications
– Chemical industry
– Petrochemical industry
– Process engineering
– Power stations
– General industry -
Advantages
–
–
–
–
–
–
–
–
–
–
–
– -
Suitability
Gate valve
-
Technical Features
- Nominal pressure
- CL 150, CL 3000
- Max. nominal size
- NPS 12
- Maximum allowable fluid temperature
- 427 °C
-
